635-JC1BA1AE06S4SB1100AA

635-JC1BA1AE06S4SB1100AA

Messko

Teslimat Seçenekleri
info@yursat.com.tr
Ücretsiz teslimat (Kapı Teslim)
Tedarik süreci min. 3-4 hafta

Messko ürünlerini Türkiye genelinde kapı teslimi olarak satın almak istiyorsanız, lütfen talebinizle ilgili ürün kodları ve miktarı içeren bilgileri, iletişim bilgilerinizle birlikte info@yursat.com.tr adresimize gönderiniz. Ekibimiz en kısa sürede sizlere satış teklifi sunacaktır.
635-JC1BA1AE06S4SB1100AA ve diğer modellerimizi içeren geniş ürün portföyümüzü görmek için aşağıdaki listeyi kontrol edebilirsiniz. Eğer ihtiyacınız olan ürünü bulamıyorsanız, lütfen bizimle iletişime geçmekten çekinmeyin, yeni talebinizi mail gönderebilir ya da Teklif İste formunu doldurabilirsiniz.

Firmamız, Messko Türkiye Distribütörü veya temsilcisi değildir. Firmamız sipariş durumunda, belirtilen ürünlerde sadece Orjinal ve yeni ürün teklifi sunmaktadır. Bu sitede gösterilen Özel marka adları ve ticari markalar ilgili sahiplerinin mülkiyetindedir.
Model Tanımı

Product MT-ST Pointer Thermometer
Product category Compact Winding Temperature
Article designation MT-ST160W/TT/4/6m
Type Compact winding dial indicating thermometer W
with analog output signal
Housing Ø 160mm, sheet metal galvanized, color RAL 7033
- cement grey
Mounting Wall mounting / shock proofed plate
View glass Laminated safety glass
Measuring range 0°C ... +160°C (160)
Sensor type Compact sensor nr. 7
Thread joint G1B
Mounting dimension 150
Length of Capillary tube 6 m
Protection Stainless steel protection Ø 4mm
Number of switches 4
Type of Switches Standard
Switching capacity 5A/250VAC or 0.4A/250VDC
Configuration of switches Every CO
Order of switches 1 + 2 close switching
Electrical connection 4x M25x1,5 Cable gland conn.
Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh)
Colour inscription Background white, lettering black
Analog output signal 4...20mA
Protection class IP55
Ambient temperature -50°C to +80°C
Maximum pointer red
Quantity of operation instructions for the
transformer-manufacturer
1
Language of operating instructions for the
transformer-manufacturer
Engl

Tüm Modeller (Messko)
Product MT-ST Pointer Thermometer Product category Trasy Oil Temperature Article designation MT-ST160F/4/6m Type Trasy oil dial indicating thermometer Housing Ø 160mm, sheet metal, galvanized, painted RAL7033 Mounting Wall mounting / shock proofed plate View glass Laminated safety glass Measuring range -20°C ... +140°C (160) Sensor type Trasy sensor nr. 2 Length of Capillary tube 6 m Protection PVC/stainless steel Number of switches 4 Type of Switches Standard Switching capacity 5A/250VAC or 0.4A/250VDC Configuration of switches Every CO Order of switches 1 + 2 close switching Electrical connection 4x M25x1,5 Cable gland conn. Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh) Colour inscription Background white, lettering black Protection class IP55 Ambient temperature -50°C to +80°C Maximum pointer red Quantity of operation instructions for the transformer-manufacturer 1 Language of operating instructions for the transformer-manufacturer
635-At1ac1zk06s4sb1100aa

Product MT-ST Pointer Thermometer Product category Trasy Oil Temperature Article designation MT-ST160F/4/6m Type Trasy oil dial indicating thermometer Housing Ø 160mm, sheet metal, galvanized, painted RAL7033 Mounting Wall mounting / shock proofed plate View glass Laminated safety glass Measuring range -20°C ... +140°C (160) Sensor type Trasy sensor nr. 2 Length of Capillary tube 6 m Protection PVC/stainless steel Number of switches 4 Type of Switches Standard Switching capacity 5A/250VAC or 0.4A/250VDC Configuration of switches Every CO Order of switches 1 + 2 close switching Electrical connection 4x M25x1,5 Cable gland conn. Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh) Colour inscription Background white, lettering black Protection class IP55 Ambient temperature -50°C to +80°C Maximum pointer red Quantity of operation instructions for the transformer-manufacturer 1 Language of operating instructions for the transformer-manufacturer

1ZBA566008-E OTI MESSKO (MT-ST 160SK/4/6M)

WTI, MESSKO, 4-20 mA TRDC
TEMP RANGE -20C TO +140C SENSOR N 2 STAINLESS TEEL TUBE LENGTH 8 MT. COLOR BOX RAL 7033 CEMENT GREY. DIAMETER OF TUBE 8mm. DESCRIPTION COLORS TEXT IN BLACK AND BACKGROUND IN WHITE. SWITHCED 1+2 BRASS NICKEL PROTECTION IP55 INSULATION 2.5 Kv for 1 MINUTE CAP 5 AMPS TO 255 V 40-60Hz OHMICA CHARGE.
MT-ST 160F (XK-2392).

TEMP RANGE -20C TO +140C SENSOR N 2 STAINLESS TEEL TUBE LENGTH 8 MT. COLOR BOX RAL 7033 CEMENT GREY. DIAMETER OF TUBE 8mm. DESCRIPTION COLORS TEXT IN BLACK AND BACKGROUND IN WHITE. SWITHCED 1+2 BRASS NICKEL PROTECTION IP55 INSULATION 2.5 Kv for 1 MINUTE CAP 5 AMPS TO 255 V 40-60Hz OHMICA CHARGE.

TEMP RANGE 0 C TO +160C SENSOR N 2 STAINLESS TEEL TUBE LENGTH 8 MT. COLOR BOX RAL 7033 CEMENT GREY. DIAMETER OF TUBE 8mm. DESCRIPTION COLORS TEXT IN BLACK AND BACKGROUND IN WHITE. SWITHCED 1+2+3+4 (RED+BLUE+GREEN) PROTECTION IP55 INSULATION 2.5 Kv for 1 MINUTE 2% ERROR OF MEASUREMENT FIELD. CAP 5 AMPS TO 255 V 40-60Hz OHMICA CHARGE.
MT-ST 160F (XK-2424).

TEMP RANGE 0 C TO +160C SENSOR N 2 STAINLESS TEEL TUBE LENGTH 8 MT. COLOR BOX RAL 7033 CEMENT GREY. DIAMETER OF TUBE 8mm. DESCRIPTION COLORS TEXT IN BLACK AND BACKGROUND IN WHITE. SWITHCED 1+2+3+4 (RED+BLUE+GREEN) PROTECTION IP55 INSULATION 2.5 Kv for 1 MINUTE 2% ERROR OF MEASUREMENT FIELD. CAP 5 AMPS TO 255 V 40-60Hz OHMICA CHARGE.

1ZBA566008-J Product MT-ST Pointer Thermometer Product category Compact Oil Temperature Article designation MT-ST160SK/TT/4/8m Type Compact Oil dial indicating thermometer with analog output signal Housing Ø 160mm, sheet metal, galvanized, painted RAL7033 Mounting Wall mounting / shock proofed plate View glass Laminated safety glass Measuring range -20°C ... +140°C (160) Sensor type Compact sensor nr. 7 Thread joint G1B Mounting dimension 150 Length of Capillary tube 8 m Protection PVC-Protection Ø 8mm Number of switches 4 Type of Switches Standard Switching capacity 5A/250VAC or 0.4A/250VDC Configuration of switches Every CO Order of switches 1 + 2 close switching Electrical connection 4x M25x1,5 Cable gland conn. Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh) Colour inscription Background white, lettering black Analog output signal 4...20mA Protection class IP55 Ambient temperature -50°C to +80°C Maximum pointer red Quantity of operation instructions for the transformer-manufacturer 1 Language of operating instructions for the transformer-manufacturer English Goods tariff No. 90251900
635-PC1AA1AP08S4SB1100AA

1ZBA566008-J Product MT-ST Pointer Thermometer Product category Compact Oil Temperature Article designation MT-ST160SK/TT/4/8m Type Compact Oil dial indicating thermometer with analog output signal Housing Ø 160mm, sheet metal, galvanized, painted RAL7033 Mounting Wall mounting / shock proofed plate View glass Laminated safety glass Measuring range -20°C ... +140°C (160) Sensor type Compact sensor nr. 7 Thread joint G1B Mounting dimension 150 Length of Capillary tube 8 m Protection PVC-Protection Ø 8mm Number of switches 4 Type of Switches Standard Switching capacity 5A/250VAC or 0.4A/250VDC Configuration of switches Every CO Order of switches 1 + 2 close switching Electrical connection 4x M25x1,5 Cable gland conn. Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh) Colour inscription Background white, lettering black Analog output signal 4...20mA Protection class IP55 Ambient temperature -50°C to +80°C Maximum pointer red Quantity of operation instructions for the transformer-manufacturer 1 Language of operating instructions for the transformer-manufacturer English Goods tariff No. 90251900

COMPACT / MT-ST 160SK/4/6M
POINTER THERMOMETER

COMPACT / MT-ST 160SK/4/6M

Product MT-ST Pointer Thermometer Product category Compact Oil Temperature Article designation MT-ST160SK/4/2m Type Oil dial indicating thermometer Compact Housing Ø 160mm, sheet metal galvanized, color RAL 7033 - cement grey Mounting Wall mounting / shock proofed plate View glass Laminated safety glass Measuring range -20°C ... +140°C (160) Sensor type Compact sensor nr. 7 Thread joint G1B Mounting dimension 150 Length of Capillary tube 2 m Protection Stainless steel protection Ø 4mm Number of switches 4 Type of Switches Standard Switching capacity 5A/250VAC or 0.4A/250VDC Configuration of switches Every CO Order of switches 1 + 2 close switching Electrical connection 4x M25x1,5 Cable gland conn. Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh) Colour inscription Background white, lettering black Protection class IP55 Ambient temperature -50°C to +80°C Maximum pointer red
635-OC1AA1AE02S4SB1100AA

Product MT-ST Pointer Thermometer Product category Compact Oil Temperature Article designation MT-ST160SK/4/2m Type Oil dial indicating thermometer Compact Housing Ø 160mm, sheet metal galvanized, color RAL 7033 - cement grey Mounting Wall mounting / shock proofed plate View glass Laminated safety glass Measuring range -20°C ... +140°C (160) Sensor type Compact sensor nr. 7 Thread joint G1B Mounting dimension 150 Length of Capillary tube 2 m Protection Stainless steel protection Ø 4mm Number of switches 4 Type of Switches Standard Switching capacity 5A/250VAC or 0.4A/250VDC Configuration of switches Every CO Order of switches 1 + 2 close switching Electrical connection 4x M25x1,5 Cable gland conn. Inscription terminal cover 6 lg. Std. (de,en,es,fr,tr,zh) Colour inscription Background white, lettering black Protection class IP55 Ambient temperature -50°C to +80°C Maximum pointer red

635-AT1AC1ZP12S4SB1100AA
635-BT1BC1ZP08S4SB1200AA
